Room No : A-104L4
Carpet Area : 75 Square Meters

Modern DSP Laboratory :

• Advanced Digital Signal Processing introduces implementation of algorithms in DSP design and analysis techniques.
• The Laboratory is in Room No A 104, L2 with Carpet area of 95 Square meters with sufficient numbers of working table and other required infrastructure
• The Major equipments are Desktop computers, TMS DSP Starter kits.24 port LAN Switch.
• For Uu-Interrupted power backup 5KVA online UPS with are power backup batteries are available for conduction/practicing of the Laboratory experiments.
• The Desktops are connected with LAN and provided internet connection
  For the safety purpose Fire Extinguisher is installed in the Laboratory

Room No : A-304L1
Carpet Area : 95 Square Meters

Advanced Communication Laboratory (PG)

• Advanced Communication Lab enables to formulate and interpret the processing of signals in communication systems by designing, measuring and evaluating the circuits using laboratory instruments.
• ADC Lab deals with the latest communication techniques like Optical Fiber and Microwave Communication.

Major Equipments:

• NI USRP-2944, 8-Channel Clock Distribution
• Accessory with GPSDO, PCIE – MXI Express Interface Kit for USRP RIO
• Digital storage oscilloscope, Function generators, DC Power supply, Microwave Benches – Klystron Power Supply, VSWR Meter and microwave components,Microstripline experimental setup – Signal Source, VSWR Meter, Antenna, Isolator, Power divider, directional coupler etc, Digital Communication Trainer kits, Optical Fiber Communication, UPS 5KVA, Desk top Computers.,
